VC830L Digital Multimeter
In Stock
16,000RWF
In Stock
The VC830L Digital Multimeter is a compact and versatile measuring tool designed for professional technicians and DIY enthusiasts. It features a large LCD display with backlight for easy reading, offers a wide range of measurement functions including temperature measurement, and comes with safety features such as CAT III 600V and CAT IV 300V ratings. With auto-ranging, data hold, and low battery indicator, the VC830L is a reliable and user-friendly multimeter for accurate measurements in various electrical and electronic applications. Powered by a 9V battery, it is a portable and convenient choice for your measuring needs.
Description
The VC830L Digital Multimeter is a highly versatile and reliable measuring tool designed for professional technicians and DIY enthusiasts alike. It is a compact, handheld device that provides accurate measurements for a wide range of electrical parameters, making it ideal for various electrical and electronic applications.
The VC830L features a large, easy-to-read LCD display with a backlight, allowing users to clearly view the measured values even in dimly lit environments. The display also provides clear and intuitive symbols for various measurement functions, making it user-friendly and convenient to operate.
This digital multimeter offers a wide range of measurement capabilities, including AC/DC voltage, AC/DC current, resistance, capacitance, frequency, temperature, and continuity testing. It also features a data hold function that allows users to freeze the displayed value for easy recording and analysis. The auto-ranging feature automatically selects the appropriate measurement range, making it simple and efficient to use.
The VC830L is built to withstand tough working conditions, with its rugged design and durable construction. It is rated for CAT III 600V and CAT IV 300V safety standards, providing reliable protection against electrical hazards in various environments.
One of the standout features of the VC830L is its temperature measurement capability, which allows users to measure temperatures from -40°C to 1000°C (-40°F to 1832°F) using a type-K thermocouple probe. This makes it suitable for a wide range of temperature-related applications, such as HVAC, automotive, and industrial processes.
The VC830L also offers additional features such as a low battery indicator, auto power-off function to preserve battery life, and a built-in kickstand for hands-free operation. It is powered by a standard 9V battery, making it portable and easy to replace when needed.
the technical specifications for the VC830L Digital Multimeter:
Measurement Functions:
- AC Voltage Range: 0.1mV - 750V
- DC Voltage Range: 0.1mV - 1000V
- AC Current Range: 0.1µA - 20A
- DC Current Range: 0.1µA - 20A
- Resistance Range: 0.1Ω - 20MΩ
- Capacitance Range: 0.1nF - 20mF
- Frequency Range: 0.001Hz - 10MHz
- Temperature Range: -40°C to 1000°C (-40°F to 1832°F) with type-K thermocouple probe
- Diode Test: Yes
- Duty Cycle: 0.1% - 99.9%
Display:
- Type: LCD with backlight
- Size: 3 3/4 digits, 6000 counts
- Backlight: Yes, with adjustable brightness
Auto-Ranging: Yes
Safety Ratings:
- CAT III 600V
- CAT IV 300V
Additional Features:
- Data Hold: Yes
- Low Battery Indicator: Yes
- Auto Power-Off: Yes, after 15 minutes of inactivity
- Kickstand: Yes, built-in for hands-free operation
Power Source: 9V battery (1 x 9V alkaline battery included)
Operating Environment:
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Storage Temperature: -20°C to 60°C (-4°F to 140°F)
- Humidity: ≤ 75% RH, non-condensing
Dimensions: 170mm x 85mm x 45mm (6.7" x 3.3" x 1.8")
Weight: Approx. 350g (0.77lbs) including battery
